! Lower anchorages |
s01ag070101 |
! Tether anchorages |
s01ag070102 |
1 |
||||||||
|
U . S . -spec . models
WARNING
Do not connect two or more lower hooks onto the same anchorage ( bar ).
There are a total of 5 lower anchorages at the rear seat . The second lower anchorage from the right side is used for both the right seat and center seat . Each lower anchorage is located where the seat cushion meets the seatback .
|
Canada-spec . models |
WARNING
Do not connect two or more lower hooks onto the same anchorage ( bar ).
2 lower anchorages are provided for installing a child restraint system in the rear seat window-side seating positions . Lower anchorages for window-side seating positions may be used for a seat in the center seating position if a child restraint system manufacturer ’ s instructions permit and specify using anchors as far apart as those in this vehicle . Each lower anchorage is located where the seat cushion meets the seatback .
|
1 For left seat 2 For center seat 3 For right seat
The tether anchorages are provided at the locations shown in the above illustration .
|
Seat , Seatbelt and SRS Airbags |
||||
– CONTINUED – |
