480
Tires and Wheels
|
is worn beyond the acceptable limit and must be replaced immediately . With a tire in this condition , driving at high speeds in wet weather can cause the vehicle to hydroplane . The resulting loss of vehicle control can lead to an
accident .
|
& Rotational Direction of Tires s11av11 |
|
|
& Tire Rotation |
s11av07 |
NOTE
For safety , inspect the tire tread regularly and replace the tires before their tread wear indicators become visible .
Example of rotational direction marked on the sidewall
1 Front
If the tires have specific rotational direction , refer to the arrow marked on the side wall .
The arrow should be pointing forward direction when the wheels are fitted .
Vehicles equipped with 4 nonunidirectional tires
1 Front
