468
Cooling System
other brand or type of coolant during this period . Mixing with a different coolant will reduce the life of the coolant . When necessary to top up the coolant for any reason , use only SUBARU SUPER COOLANT .
If SUBARU SUPER COOLANT is diluted with another brand or type , the maintenance interval is shortened to that of the mixing coolant .
. Do not splash the engine coolant over painted parts . The alcohol contained in the engine coolant may damage the paint surface .
& Cooling Fan , Hose and Connections s11af03
Your vehicle employs an electric cooling fan which is thermostatically controlled to operate when the engine coolant reaches a specific temperature .
1 Normal operating range
If the radiator cooling fan does not operate even when the engine coolant temperature gauge exceeds the normal operating range , the cooling fan circuit may be defective . Refer to “ Engine Coolant Temperature Gauge ” FP154 .
Check the fuse and replace it if necessary . Refer to “ Fuses ” FP490 . If the fuse is not blown , have the cooling system checked by your SUBARU dealer .
If the frequent addition of coolant is necessary between vehicle service visits , it is recommended that you have your vehicle inspected by an authorized SUBARU dealer to check for leaks , damage , or looseness .
& Engine Coolant
! Checking the coolant level
1 “ FULL ” level mark 2 “ LOW ” level mark s11af02
s11af0201
Check the coolant level at each fuel stop .
1 . Check the coolant level on the outside of the reservoir while the engine is cool .
2 . If the level is close to or lower than the “ LOW ” level mark , add coolant up to the “ FULL ” level mark . If the reserve tank is empty , remove the radiator cap and refill coolant up to just below the filler neck as shown in the following illustration .
