Driver Monitoring System 391 |
|||
|
2 . Sit in the driver ’ s seat and face forward for a few moments .
3 . When user recognition is completed , the Hello screen appears on the center information display .
At this time , climate control settings , combination meter display ( color LCD ) basic screen , center information display basic screen , and customization settings all change based on the user information .
NOTE
. When a center information display operation switch is pressed , the user recognition screen is canceled , however user recognition continues .
|
. If user recognition fails , perform recognition again following the instructions , refer to “ When a user is not recognized ” FP391 .
. User recognition is not performed while driving .
! When a user is not recognized s07bp0402
In the following case , user recognition may not be possible and “ User recognition stopped .” may be displayed .
. There is an object blocking the camera .
Remove the obstacle and follow the reference procedure to perform user recognition again .
Refer to “ Driver Monitoring System ” FP209 .
1 Camera
|
NOTE
. User recognition may not be possible when there is dirt or fingerprints on the user recognition camera . To clean , either wipe using a soft cloth or else wipe gently using a moistened cloth that has been thoroughly wrung out .
. When the synchronized user function is turned OFF , manual repeat facial scan is not possible .
& Registering and Deleting a User s07bp05
Users can be registered in the Driver Monitoring System , and registered users can be deleted . For the user registration and delete procedures , refer to “ Driver Monitoring System ” FP209 .
NOTE
. When the Driver Monitoring System OFF indicator , Driver Monitoring System temporary stop indicator , or Driver Monitoring System warning is illuminated , the following items cannot be selected . – Register User – Delete User – Delete All Users
. User information can also be deleted by resetting the center information
– CONTINUED –
|
7
Starting and Operating
|
