BSD / RCTA 369 |
|||||||
& To Turn On / Off the BSD / RCTA s07bm09 |
BSD / RCTA OFF indicator
To turn the BSD / RCTA system on and off , operate the center information display . Refer to “ Car settings ” FP203 ( 11.6-inch display models ) or “ Vehicle setting icons ” FP221 ( dual 7.0-inch display models ).
When the BSD / RCTA system is turned OFF , the BSD / RCTA OFF indicator on the combination meter display ( color LCD ) will illuminate .
|
NOTE
. In the following cases , turn off the BSD / RCTA system . The system may not operate properly due to blocked radar waves . – When towing a trailer – When a bicycle carrier or other item is fitted to the rear of the vehicle
– When using a chassis dynamometer or free roller device , etc .
– When running the engine and making the wheels rotate while lifting up the vehicle
. If the ignition switch is turned to the “ LOCK ”/“ OFF ” position , the last known status of the system is maintained . For example , if the ignition switch is turned to the “ LOCK ”/ “ OFF ” position with the BSD / RCTA deactivated , the BSD / RCTA remains deactivated the next time the ignition switch is turned to the “ ON ” position .
|
& Certification for the BSD / RCTA s07bm06
. The U . S . and other FCC compliant countries
FCC ID : OAYSRR3A
CAUTION
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user ’ s authority to operate the equipment .
This device complies with part 15 of the FCC Rules . Operation is subject to the following two conditions : ( 1 ) This device may not cause harmful interference , and ( 2 ) this device must accept any interference received , including interference that may cause undesired operation .
|
7
