BSD / RCTA 367 |
||||
|
turned on , the brightness of the BSD / RCTA approach indicator light will not be reduced . For details about the illumination brightness control dial , refer to “ Illumination Brightness Control ” FP155 .
! BSD / RCTA approach warning buzzer ( only when reversing ) s07bm0302
A warning buzzer sounds along with flashing of the BSD / RCTA approach indicator light to warn the driver of dangers .
The setting of the warning buzzer volume can be changed by operating the center information display . For details , refer to “ Car settings ” FP203 ( 11.6-inch display models ) or “ Vehicle setting icons ” FP221 ( dual 7.0-inch display models ).
! Safety tips regarding the BSD / RCTA approach indicator light / warning buzzer s07bm0303
. In the following cases , operation of the BSD / RCTA approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings . – When a vehicle moves to the neighboring lane from a lane next to the neighboring lane
– When driving on a steep incline or on repeated sharp uphill and downhill
|
grades – When going beyond a pass – When both your vehicle and a vehicle driving on a neighboring lane are driving on the far side of each lane .
– When several narrowly-spaced vehicles are approaching in a row
– In low radius bends ( tight bends or when making turns at an intersection )
– When there is a difference in height between your lane and the neighboring lane
– Immediately after the BSD / RCTA is activated by touching “ Rear Vehicle Detection ( BSD / RCTA )”
– Immediately after the select lever is shifted to the “ R ” position
– When extremely heavy cargo is loaded in the cargo area
. During reversing , operation of the BSD / RCTA approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings under the following conditions . – When backing out of an angled parking space – When a large-sized vehicle is parked next to your vehicle ( That vehicle prevents the propagation of radar waves .)
|
– When reversing on sloped roads – When reversing at a high speed |
. The BSD / RCTA approach indicator light may illuminate when driving close to solid objects on the road or road side ( such as guardrails , tunnels and sidewalls ).
. When turning at an intersection in urban areas , or a multilane intersection , the BSD / RCTA approach indicator light may flash .
. If a building or a wall exists in the reversing direction , the BSD / RCTA approach indicator light may flash and the warning buzzer may sound .
. In the following cases , the system may detect a vehicle driving two lanes away from your vehicle . – When your vehicle drives on the
– CONTINUED –
|
7
Starting and Operating
|
