Rear View Camera 359 |
||||||
|
neutral detergent to remove the wax .
. The camera lens has a hard coating to help prevent scratches . However , when washing the vehicle or cleaning the camera lens , be careful not to scratch the camera lens . Do not use a washing brush directly on the camera lens . The image quality of the rear view camera may deteriorate .
. Strong light shined on the camera lens may develop vertical lines around the light source . This is not a malfunction .
. Under the fluorescent light , the display may flicker . However , this is not a malfunction .
. The image of the rear view camera may be slightly different from the actual color of the objects .
. If there is a malfunction on the center information display , refer to “ Malfunctions of the Center Information Display ” FP443 .
& How to Use the Rear View Camera s07br01
When the select lever is set to “ R ”, the rear view camera automatically displays the rear view image from the vehicle . When the lever is set to other positions , the image before setting to “ R ” is displayed .
|
1 . Set the ignition switch to “ ON ”. 2 . Set the select lever to “ R ”.
NOTE
. The image of the rear view camera is horizontally reversed as is the case with the vehicle inside mirror or the outside mirror .
. When “ Rear Camera Delay Control ” is on , the rear view image will be displayed on the center information display for a certain period of time after the select lever is shifted to a position other than the “ P ” position from “ R ”. To turn the function on and off , refer to “ General settings ” FP198 ( 11.6-inch display models ) or “ General settings ” FP215 ( dual 7.0-inch display models ).
. It may be difficult to see the image of the rear view camera in the following cases . This is not a malfunction of the camera . – The vehicle is in a dark place ( at night , in a tunnel , etc .). – The vehicle is in an extremely hot or cold place .
– An object ( such as raindrops , snow , dirt , etc .) that disturbs the view of the rear view camera sticks to the lens of the camera .
|
– Strong light is shining directly on the camera lens ( occasionally , there are vertical lines on the screen ).
& Viewing Range on the Screen s07br02
CAUTION
The range that can be viewed with the rear view camera is limited . Always be sure to check with your eyes when moving backward and proceed slowly . Otherwise , it may cause an accident or injury .
|
Range of view |
7
Starting and Operating
|
||
– CONTINUED – |
