Auto Start Stop System 353 |
|||||||
|
. When starting backward facing uphill . When starting forward facing downhill . While the parking brake is applied
. While the ignition switch is in the “ ACC ” or “ OFF ” position
|
. While the Vehicle Dynamics Control warning light is illuminated . Refer to “ Vehicle Dynamics Control Warning Light / Vehicle Dynamics Control Operation Indicator Light ” FP169 .
. While the Auto Start Stop warning light is illuminated . Refer to “ Auto Start Stop Warning Light ( Yellow )” FP177 .
When using the Hill start assist system , a braking effect may be felt even after the brake pedal has been released .
CAUTION
The braking power of the Hill start assist system may not be sufficient when strong braking power is needed ( e . g ., when towing a trailer ).
|
NOTE
A slight jolt may be felt when the vehicle begins to move forward after being reversed .
|
7-18 . Auto Start Stop System
s07bh
The Auto Start Stop system is designed to automatically stop and restart the engine when the vehicle is stationary for a short period of time ( while waiting for a traffic light or in a traffic jam ) after the engine has warmed up . The system operates in order to reduce fuel consumption , exhaust emissions and undesired idling noise .
|
& System Operation |
WARNING
s07bh01
Turn off the Auto Start Stop system before towing the vehicle .
CAUTION
The Auto Start Stop system is designed to automatically stop and restart the engine for a short period of time during idling . Do not use the system when parking the vehicle normally .
So that it can be used safely and comfortably , in addition to driver operations , the Auto Start Stop system is designed to constantly monitor the vehicle conditions
|
7
Starting and Operating
|
|
– CONTINUED – |
