Continuously Variable Transmission 331 |
|||||
|
accidental gear shifting .
NOTE
Please read the following points carefully and bear them in mind when using the manual mode .
. If you attempt to shift down when the engine speed is too high , i . e ., when a downshift would push the tachometer needle beyond the red zone , beeps will be emitted to warn you that the downshift is not possible .
. If you attempt to shift up when the vehicle speed is too low , the transmission will not respond .
. You can perform a skip-shift ( for example , from 4th to 2nd ) by operating the shift paddle twice in rapid succession .
. The transmission automatically selects 1st gear when the vehicle stops moving .
. If the temperature of the transmission fluid becomes too high , the AT OIL TEMP warning light will illuminate . Immediately stop the vehicle in a safe place and let the engine idle until the warning light turns off .
|
& Selection of “ L ” ( If Equipped ) s07bg03 |
“ L ” is for using engine braking when going down a hill , etc . To select this mode , move the select lever from the “ D ” position to the “ L ” position .
When selected , the indicator “ L ” will
|
illuminate on the combination meter .
To deselect “ L ”, move the select lever to the “ D ” position .
& Driving Tips s07bg05
NOTE
If the accelerator and brake pedals are depressed at the same time , driving torque may be restrained . This is not a malfunction .
. On a road surface where there is a risk of wheelspin ( for example , a snow- or gravel-covered road ), you can pull away from a standstill safely and easily by first selecting the 2nd gear of the manual mode .
. Always apply the foot or parking brake when the vehicle is stopped in the “ D ” or “ R ” position .
. Make sure to apply the parking brake when parking your vehicle . Do not hold the vehicle with only the transmission .
. Do not keep the vehicle in a stationary position on an uphill grade by using the “ D ” position . Use the brake instead .
. The engine may , on rare occasions , knock when the vehicle rapidly accelerates or rapidly pulls away from a standstill . This phenomenon does not indicate a malfunction .
|
7
Starting and Operating
|
