Wireless Charger 293 |
||||
|
! Indicator light patterns
Indicator light
Off
Green ( illuminated )
Orange ( illuminated )
Green and orange illuminate alternately
s06bh0102
Interpretation The wireless charger is turned off
Standby ( ready for charging )* 1
Charging is complete * 2 A mobile device is in the charging area ( a mobile device is being detected )
Charging
Quick charging is in progress
* 1 : No power is output for charging when the wireless charger is in standby mode . Even if metal objects are placed on the charging tray in this state , they will not overheat .
* 2 : For some mobile devices , the indicator light remains orange even after charging is complete .
|
! List of warnings
Indicator light
Flashes orange once per second
Repeatedly flashes orange three times
Possible causes
A communication error occurred between the wireless charger and the access key fob .
Metallic foreign object detected . A foreign object is detected between the mobile device and the charging area . The mobile device is out of alignment : The overheat prevention function of the charging coils was triggered because the mobile device ’ s charging coils were out of alignment with the charging area .
Solution
s06bh0103
If the engine is running , stop the engine and restart it . If the ignition switch is in “ ACC ”, start the engine once .
Remove any foreign objects between the mobile device and the charging area . Remove the mobile device from the charging area , check that the activation indicator light is illuminating in green again , and place the device in the center of the charging area . If there is a case or cover on your mobile device , be sure to remove it .
|
Indicator light
Repeatedly flashes orange four times
Possible causes
|
The temperature inside the wireless charger has increased .
Solution
Remove the mobile device from the charging area temporarily to stop charging . When the temperature of the heavy electrical equipment cools down , start charging the device again .
NOTE
If you hear noise on the AM radio while your device is charging , you may be able to reduce the noise by changing the charging frequency .
To change the charging frequency , press and hold the power switch to turn on the system .
After a certain amount of time , the indicator light will flash orange twice to indicate the frequency switch .
WARNING
. For safety reasons , drivers must not operate a charging mobile device while driving .
– CONTINUED –
|
