282
Interior Light
6-1 . Interior Light |
Doing so could damage your eyes . |
FP283 . |
CAUTION |
s06aa |
|
|
|
|
! Door interlock switch |
s06aa0602 |
& Dome Light |
|
s06aa01 |
When leaving your vehicle , make sure the lights are turned off to avoid battery discharge .
& Map Lights
! Map light switches s06aa06
s06aa0606
To turn on the map light , press the lens . To turn it off , press the lens again .
CAUTION
Do not keep watching the light source because they use LEDs .
1 Door interlock switch
The door interlock switch has the following positions .
OFF : The map lights do not illuminate automatically in conjunction with a door opening . However , the lights can be turned on manually by pressing the map light lens .
DOOR : The map lights illuminate automatically when any of the doors ( other than the rear gate ) is opened even while the map light is off . Several seconds after all the doors ( other than the rear gate ) are closed , the map lights gradually turn off . For details , refer to “ OFF Delay Timer ”
1 ON 2 DOOR 3 OFF
The dome light switch has the following positions .
ON : The light remains on continuously . OFF : The light remains off .
DOOR : The dome light illuminates automatically in the following cases .
. Any of the doors or the rear gate is opened .
. The doors or the rear gate are unlocked using the keyless access function ( if equipped ). Refer to “ Locking and Unlocking with “ Keyless Access ” Entry
