RADIO OPERATION
MULTICAST
On the FM radio frequency most digital stations have additional programs on one FM station .
1 . Select . � Each time is selected , the channel can be changed .
� HD Radio TM Technology improves the audio quality of your local stations and delivers a crystal clear digital signal to your receiver . HD Radio Technology enables local radio stations to broadcast a clean digital signal . AM sounds like today ’ s FM and FM sounds like clear digital .
� FM stations can provide additional digital-only audio programming on HD2 / HD3 Channels .
� EXAMPLE : 101.1 HD1 101.1 HD2 101.1 HD3
NOTE
� HD Radio™ stations can be preset .
� An orange will be displayed on the screen when in digital . The will first appear in a gray color indicating the digital station is being acquired . Once the digital signal is acquired , the logo will change to a bright orange color .
� The song title and artist name will appear on the screen when available by the radio station . The radio station can send album pictures when available .
� As a user works through the analog radio stations , ( where applicable ) the radio receiver will automatically tune from an analog signal to a digital signal within 5 seconds .
� Program info provides song name , artist , station ID , and other relevant data to your receiver .
� Visual images of album cover art and station logos are broadcasted with the audio to your receiver , such as Album Art , historical photographs , still art from live broadcasts , station logos , among other related content .
160
� Allows HD Radio receivers to store content ( songs / programs and data ) in a buffer . Playback shall start at any point in the buffer and shall continue until the end of the buffer or until the user has selected to stop playback . Live Pause has the ability to store both analog and digital content in the buffer .
