1-38
Seat , seatbelt and SRS airbags / Child restraint systems
|
dents .
Some types of child restraint systems can be installed on the rear seat of your vehicle without use of the seatbelts . Such child restraint systems are secured to the dedicated anchorages provided on the vehicle body . The lower and tether anchorages are sometimes referred to as the LATCH system ( Lower Anchors and Tethers for CHildren ).
|
! Lower anchorages |
|
|
|
S01AG070101 |
! Tether anchorages |
|
S01AG070102 |
WARNING
Do not connect two or more lower hooks onto the same anchorage ( bar ).
The tether anchorages ( upper anchorages ) are provided at the locations shown in the above illustration . For details , refer to “ Top tether anchorages ” F1-41 .
Your vehicle is equipped with four lower anchorages ( bars ) and three upper anchorages ( tether anchorages ) for accommodating such child restraint systems .
Two lower anchorages ( bars ) are provided for installing a child restraint system on the rear seat window-side seating positions . Lower anchorages ( bars ) for window-side seating positions may be used for a seat in the center seating position if a child restraint system manufacturer ’ s instructions permit and specify using anchors as far apart as those in this vehicle . Each lower anchorage is located where the seat cushion meets the seatback .
