1-8
Seat , seatbelt and SRS airbags / Seats
Lock release knob |
1 ) |
Unlocked |
2 ) |
Locked |
A ) |
Unlocking marker in red |
To return the seatback to its original position , raise the seatback until it locks into place and make sure that the unlocking marker on the lock release knob is no longer visible .
WARNING
When you return the seatback to its original position , check that the unlocking marker on the lock release knob is not visible . Also , move the seatback back and forth to confirm that it is securely in place . If it is not securely fixed in place , it may suddenly fold down in the event of sudden braking , or objects may move out from the cargo area . Both could cause serious injury or death .
& Head restraints WARNING
S01AQ04
The front seat head restraints are designed to be installed into the front seats only . The rear seat head restraints are designed to be installed into the rear seats only . Do not attempt to install the front seat head restraints into the rear seats , or the rear seat head restraints into the front seats .
NOTE
It is possible to adjust the angle of the front seat head restraints only . When installing the front seat head restraints , make sure that the angle of the head restraints can be adjusted .
! Front seats
S01AQ0401
Both the driver ’ s seat and the front passenger ’ s seat are equipped with head restraints . Both head restraints are adjustable in the following ways .
! Height adjustment
1 ) |
Head restraint |
2 ) |
Release button |
S01AQ040101
To raise : Pull the head restraint up . To lower :
Push the head restraint down while pressing the release button on the top of the seatback .
To remove :
While pressing the release button , pull out the head restraint .
