8-16
Driving tips / Trailer hitch
Trailer hitch
WARNING
S08AK
. Never exceed the maximum weight specified for the trailer hitch . Exceeding the maximum weight could cause an accident resulting in serious personal injuries . Permissible trailer weight changes depending on the situation . For possible recommendations and limitations , refer to “ Trailer towing ” F8-18 .
. Trailer brakes are required when the tow load exceeds 1,000 lbs ( 453 kg ). Be sure your trailer has safety chains and that each chain will hold the trailer ’ s maximum gross weight . Towing trailers without safety chains could create a traffic safety hazard if the trailer separates from the hitch due to coupling damage or hitch ball damage .
. Be sure to check the hitch pin and safety pin for positive locking placement before towing a trailer . If the ball mount separates from the receiver the trailer could become loose and create a traffic
safety hazard .
. Although towing regulations for trailer or caravan vehicles vary by state / region , all regulations agree that specifications such as the maximum gross trailer weight must not exceed the lesser of the following :
– Maximum gross trailer weight
– Maximum gross tongue weight
– GVWR – GAWR
. Failure to comply with the procedures set forth will not only compromise your safety , but will also negate your insurance coverage and / or may violate the state road and traffic acts and regulations .
. It is recommended to only use the Genuine Subaru Ball Mount developed for use with this trailer hitch available at your Subaru dealership . Use the hitch only as a weight carrying hitch . Do not use with any type of weight distributing hitch .
. The standard bumper beam must be installed after you remove the trailer hitch . Consult a SUBARU dealer for purchase of a standard bumper beam if you do not have the original .
. Safety performance is decreased and there is increased risk of injury to passengers in the case of an accident if the SUBARU genuine trailer hitch or a standard bumper beam is not installed . One of them must always be installed on the vehicle .
. If a trailer hitch is installed , it is not possible to install the rear towing hook .
The maximum gross trailer weight and maximum gross tongue weight are indicated in the following table .
When towing a trailer with brakes
Maximum gross trailer weight
Maximum gross tongue weight
1,500 lbs ( 680 kg ) 150 lbs ( 68 kg )
When towing a trailer without brakes Maximum gross trailer weight
Maximum gross tongue weight
1,000 lbs ( 453 kg ) 100 lbs ( 45 kg )
