Instruments and controls / Multi-function display ( color LCD ) 3-63
without applying the setting changes .
! Camera Settings ( if equipped )
S03BP2809
You can set the front camera display settings .
! Brightness setting
S03BP280901
1 . Select “ Brightness ” from the 2nd menu in the setting screen . Refer to “ Setting screen ” F3-58 .
! Contrast setting
S03BP280902
1 . Select “ Contrast ” from the 2nd menu in the setting screen . Refer to “ Setting screen ” F3-58 .
! Camera shift link setting
S03BP280903
1 . Select “ Camera Shift Link ” from the 2nd menu in the setting screen . Refer to “ Setting screen ” F3-58 .
2 . Select the brightness level by using the control switches .
3 . Press the “ / SET ” button to confirm the setting .
2 . Select the contrast level by using the control switches .
3 . Press the “ / SET ” button to confirm the setting .
2 . Select “ On ” or “ Off ” by using the control switches .
3 . Select “ Set ” to exit settings . Select “ Go Back ” to return to the previous screen without applying the setting changes .
– CONTINUED –
