3-30
Instruments and controls / Warning and indicator
& SI-DRIVE indicator light ( if equipped )
S03AE52
& Select lever / gear position indicator
S03AE43
1 ) |
Intelligent ( I ) mode indicator |
2 ) |
Sport ( S ) mode indicator |
This light indicates the current SI-DRIVE mode .
For details of SI-DRIVE mode , refer to “ SI-DRIVE ” F7-33 .
Type A 1 ) Gear position indicator
Type B |
1 ) |
Upshift indicator |
2 ) |
Downshift indicator |
3 ) |
Select lever / gear position indicator |
This indicator shows the position of the select lever .
For models with manual mode , when the manual mode is selected , the gear position indicator ( which shows the current gear selection ) and the upshift / downshift indicator light up . Refer to “ Continuously variable transmission ” F7-26 .
