Instruments and controls / Warning and indicator 3-13
: CHECK ENGINE warning light / Malfunction indicator light
: Coolant temperature low indicator light / Coolant temperature high warning light
: Charge warning light : Oil pressure warning light : Engine low oil level warning light
: Windshield washer fluid warning light
: AT OIL TEMP warning light ( CVT models )
: Low tire pressure warning light ( U . S . -spec . models )
/ : ABS warning light
/ : Brake system warning light ( red ) : Low fuel warning light
: Hill start assist warning light / Hill start assist OFF indicator light
: AWD warning light ( CVT models ) : Power steering warning light
: Vehicle Dynamics Control warning light / Vehicle Dynamics Control operation indicator light
: Vehicle Dynamics Control OFF indicator light
: Auto Start Stop warning light / Auto Start Stop OFF indicator light ( yellow ) ( if equipped )
: Auto Start Stop indicator light ( green ) ( if equipped )
: Auto Start Stop No Activity Detected indicator light ( if equipped )
If any lights fail to illuminate , it indicates a burned-out bulb or a malfunction of the corresponding system .
Consult your authorized SUBARU dealer for repair .
& Seatbelt warning light and chime
S03AE01
Your vehicle is equipped with a seatbelt warning device at the driver ’ s and front passenger ’ s seat , as required by current safety standards .
With the ignition switch turned to the “ ON ” position , this device reminds the driver and front passenger to fasten their seatbelts by illuminating the warning lights in the locations indicated in the following illustration and sounding a chime .
Driver ’ s warning light
Front passenger ’ s warning light
– CONTINUED –
