3-10
Instruments and controls / Meters and gauges
RESET switch .
The indicators will turn off when : – The TRIP RESET switch is not operated for approximately 10 seconds . – The driver ’ s door is opened and then closed .
& Fuel gauge
1 ) |
TRIP RESET switch |
2 ) |
Type A combination meter |
3 ) |
Type B combination meter |
S03AD07
The fuel gauge is displayed when the ignition is in the “ ON ” position , and it shows the approximate amount of fuel remaining in the tank .
The gauge indication may change slightly during braking , turning or acceleration due to fuel level movement in the tank .
NOTE
. You will see the “ ” sign in the fuel gauge . This indicates that the fuel filler lid is located on the right side of the vehicle . . If you press the TRIP RESET switch while the ignition switch is in the “ LOCK ”/“ OFF ” or “ ACC ” position , the fuel gauge will light up and indicate the amount of fuel remaining in the tank .
The indicators will turn off when : – The TRIP RESET switch is not operated for approximately 10 seconds . – The driver ’ s door is opened and then closed .
& ECO gauge ( if equipped )
1 ) |
Type A combination meter |
2 ) |
Type B combination meter |
S03AD12
The ECO gauge shows the difference between the current rate of fuel consumption and the average rate of fuel consumption since the trip meter was last reset .
If the ECO gauge moves towards the + side , this indicates better fuel efficiency .
NOTE
. The ECO gauge shows only an approximate indication of fuel efficiency . . After resetting the trip meter , the average rate of fuel consumption is not shown until you have driven for 1 mile ( or 1 km ). Before that time , the ECO
