Seat , seatbelt and SRS airbags / SRS airbag ( Supplemental Restraint System airbag )
The following components are monitored by the indicator :
. Front sub sensor
. Airbag control module ( including impact sensor and rollover sensor )
. Frontal airbag module – Driver ’ s side – Front passenger ’ s side . Knee airbag module ( driver ’ s side ) . Side airbag sensor . Front door impact sensor . Side airbag module . Curtain airbag sensor . Curtain airbag module
. Satellite safing sensor ( under the rear center seat )
. Seatbelt pretensioner ( driver ’ s side )
. Seatbelt pretensioner and adaptive force limiter ( front passenger ’ s side )
. Lap belt pretensioner ( front passenger ’ s side )
. Seatbelt buckle switch ( front passenger ’ s side )
. Front passenger ’ s occupant detection system sensor
. Front passenger ’ s occupant detection control module
. Front passenger ’ s frontal airbag ON and OFF indicator
. All related wiring
WARNING
If the warning light exhibits any of the following conditions , immediately stop the vehicle in a safe place , and consult a SUBARU dealer . Unless a technician checks and repairs the system as needed , the seatbelt pretensioners and / or the SRS airbag will not operate properly in the event of a collision , which may result in injury .
. Flashing or flickering of the warning light
. No illumination of the warning light when the ignition switch is first turned to the “ ON ” position
. Continuous illumination of the warning light
. Illumination of the warning light while driving
& SRS airbag system servicing
S01AH05
WARNING
. When discarding an airbag module or scrapping the entire vehicle damaged by a collision , consult your SUBARU dealer .
. The SRS airbag has no userserviceable parts . Do not use electrical test equipment on any circuit related to the SRS airbag system . For required servicing of the SRS airbag , consult your nearest SUBARU dealer . Tampering with or disconnecting the system ’ s wiring could result in accidental inflation of the SRS airbag or could make the system inoperative , which may result in serious injury .
CAUTION
If you need service or repair in areas indicated in the following list , have the work performed by an authorized SUBARU dealer . The SRS airbag control module , impact sensors and airbag modules are stored in these areas .
. Under the center of the instrument panel
. On both the right and left sides at the front of the vehicle
. Steering wheel and column and nearby areas
. Bottom of the steering column and nearby areas
