1-30
Seat, seatbelt and SRS airbags/Child restraint systems
position to be safe. For details, refer
to “Where to place a child restraint
system” F1-27.
3. Run the lap and shoulder belt through
or around the child restraint system follow-
ing the instructions provided by its manu-
facturer.
4. Insert the tongue plate into the buckle
until you hear a click.
1. Move the seatback back and forth to
confirm that it is securely locked into place.
– Check that the red colored unlock-
ing marker which is attached to the
bottom of the lock release knob is
invisible. For details, refer to “Folding
down the rear seatback” F1-6.
2. Place the child restraint system in the
rear seating position.
WARNING
When you intend to install a child
restraint system in the rear center
seating position, if the child restraint
system does not fit snugly against
the contours of the rear center seat
cushion, install the child restraint
system in the window-side seating
5. Take up the slack in the lap belt.
6. If using the seatbelt in the ALR mode is
recommended by the manufacturer’s in-
structions supplied with the child restraint
system, perform the following procedure.
(1) Pull out the seatbelt fully from the
retractor to change the retractor over from
the Emergency Locking Retractor (ELR) to
the Automatic Locking Retractor (ALR)
mode.
(2) Allow the belt to rewind into the
retractor. As the belt is rewinding, clicks
will be heard which indicate the retractor
functions as ALR.
7. Push and pu
