Maintenance and service/Fuses
replaced, certain internal settings can be
restored only by pairing the vehicle to a
smartphone via Bluetooth, or by visiting a
SUBARU dealer. Until those internal set-
tings are restored, certain convenience
features, including the “Service Appoint-
ment Scheduler,” may be unavailable.
1)
2)
3)
11-35
Fuses
S11BB
CAUTION
Never replace a fuse with one having
a higher rating or with material other
than a fuse because serious damage
or a fire could result.
The fuses are designed to melt during an
overload to prevent damage to the wiring
harness and electrical equipment. The
fuses are located in two fuse boxes.
Cap
Upper level
Lower level
It is unnecessary to periodically check the
battery fluid level or periodically refill with
distilled water.
However, if the battery fluid level is below
the lower level, remove the cap. Fill to the
upper level with distilled water.
CAUTION
Never use more than 10 amperes
when charging the battery because
it will shorten battery life.
For “SUBARU STARLINK Safety and
Security” without navigation system:
When the vehicle battery is discharged or
One is located under the instrument panel
behind the fuse box cover on the driver’s
seat side. To remove the cover, pull it out.
– CONTINUED –
