11-18 Maintenance and service/Brake pedal
Brake pedal
S11AR
Check the brake pedal free play and
reserve distance according to the main-
tenance schedule in the “Warranty and
Maintenance Booklet”.
If the free play is not within proper
specification, contact your SUBARU deal-
er.
& Checking the brake pedal re-
serve distance
& Checking the clutch function
S11AS01
Check the clutch engagement and disen-
gagement.
1. With the engine idling, check that there
are no abnormal noises when the clutch
pedal is depressed, and that shifting into
1st or reverse feels smooth.
2. Start the vehicle by releasing the pedal
slowly to check that the engine and
transmission smoothly couple without
any sign of slippage.
S11AR01
1)
1)
0.02 – 0.11 in (0.5 – 2.7 mm)
S11AS
Check the clutch pedal free play according
to the maintenance schedule in the “War-
ranty and Maintenance Booklet”.
S11AR02
& Checking the brake pedal free
play
Turn the ignition switch to the “LOCK”/
“OFF” position and firmly depress the
brake pedal several times. Lightly pull the
brake pedal up with one finger to check the
free play with a force of less than 2 lbf (10
N, 1 kgf).
Clutch pedal (MT models)
More than 2.56 in (65 mm)
Depress the pedal with a force of approxi-
mately 66 lbf (294 N, 30 kgf) and measure
the distance between the upper surface of
the pedal pad and the floor.
When the measurement is smaller than
the specification, or when the pedal does
not operate smoothly, contact with your
SUBARU dealer.
