In case of emergency/Towing
the vehicle and stow it in the tool bucket.
Fit the towing hook cover on the bumper.
! Front tie-down hooks
9-15
! Rear tie-down holes
S09AF0106
S09AF0107
WARNING
. Do not use the towing hook
except when towing your vehicle.
. Be sure to remove the towing
hook after towing. Leaving the
towing hook mounted on the
vehicle could interfere with prop-
er operation of the fuel pump
shut off function when the vehi-
cle is struck from behind.
CAUTION
The front tie-down hooks are located
between each of the front tires and the
front bumper.
To prevent deformation to the bum-
per and the towing hook, do not
apply excessive load to the towing
hook.
1)
Rear tie-down hole
The rear tie-down holes are located near
each of the jack-up reinforcements.
There is a plug in each rear tie-down hole.
To use the rear tie-down holes, remove the
– CONTINUED –
