7-72
Starting and operating/Reverse Automatic Braking System
again, consult your SUBARU dealer.
. The settings will be restored as
follows when the select lever is shifted
to the “R” position next time.
– Reverse Automatic Braking sys-
tem settings: default (ON setting)
– Object detection warning beep-
ing sound: the setting selected by
operating the combination meter
display (color LCD)
Also, the following settings can be chan-
ged by operating the combination meter
display (color LCD).
. Warning volume
. Sonar audible alarm ON/OFF & RAB warning indicator
For details, refer to “Menu screens” F3-
38. If the Reverse Automatic Braking System
malfunctions, the above indicator illumi-
nates on the combination meter. Contact
the nearest SUBARU dealer for details.
S07BN07
& Handling of the sonar sen-
sors
S07BN06
The 4 sonar sensors are located in the rear
bumper. To ensure the proper operation of
the Reverse Automatic Braking system,
observe the following precautions.
1)
2)
RAB malfunction message
RAB warning indicator
. Do not affix any stickers or other items
on the sonar sensor or the bumper surface
near the sonar sensors.
. Always keep the sonar sensor and the
rear bumper surface near the sonar
sensors clean.
. Do not modify the rear bumper.
. Do not paint the bumper near the sonar
sensors.
. Do not apply strong impacts to the rear
bumper near the sonar sensors. If a sensor
becomes misaligned, a system malfunc-
