7-70
Starting and operating/Reverse Automatic Braking System
! When the vehicle is being stopped
by the system
S07BN0303
! After the vehicle is stopped by the
system
S07BN0304
illuminates.
– There is ice, snow, mud, or other
substance on the sonar sensors.
– The select lever was shifted to R when
there is an obstacle located close to the
rear bumper.
– A sound with a frequency close to that
of the sonar used by the Reverse Auto-
matic Braking system was detected.
NOTE
Depress brake pedal warning
1) Warning message
Make sure to depress the brake pedal
once the vehicle has been stopped by
automatic braking. Until the brake pedal is
depressed, a message will be displayed
on the audio/navigation monitor and the
continuous beep will remain sounding.
At this time, a warning message is also
displayed on the combination meter dis-
play (color LCD).
RAB OFF indicator: illuminates when the
Reverse Automatic Braking system is turned
OFF.
After the brake pedal is depressed, the
Reverse Automatic Braking system OFF
indicator will illuminate and the system will
temporarily stop operating. The Reverse
Automatic Braking system OFF indicator
will turn off when the select lever is shifted
to a position other than the “R” position.
The system will operate again the next
time the select lever is shifted to “R”
position.
In circumstances such as the following, the
Reverse Automatic Braking system auto-
matically stops operating and the Reverse
Automatic Braking system OFF indicator
Automatic braking only holds the vehi-
cle for 2 seconds. Before the automatic
brake is released, a warning sound (3
short beeps followed by a long beep)
will activate to alert the driver that the
automatic will be released.
