Starting and operating / Reverse Automatic Braking System 7-67
– The ground clearance is significantly reduced due to the vehicle’ s loading condition, etc. – When the sonar sensor is misaligned due to a collision or an accident
Surrounding environment – A cloth banner, flag, hanging branch or railroad crossing bars are present in the reversing direction – When reversing on a gravel or grassy area – When reversing in an area where objects or walls are adjacent to the vehicle such as narrow tunnels, narrow bridges, narrow roads or narrow garages – Wheel tracks or a hole is present in the ground of the reversing direction – When reversing over a drainage cover( grate cover)
– The path of the reversing direction is inclined such as on a steep uphill – A curb is present in the reversing direction – When reversing downhill
– When reversing on an uneven road
. In circumstances such as the following, it may not be possible to avoid a collision even when the system operates normally. – The tire air pressure is not correct. – The tires have become worn. – Tires which are not the designated size are installed. – Emergency repairs were performed using a puncture repair kit. – The suspension was modified. – Tire chains are installed. – Vehicle driving is unstable due to accident or malfunction.
– CONTINUED –
