7-28
Starting and operating/Continuously variable transmission
CAUTION
Do not place or hang anything on the
shift paddles. Doing so may result in
accidental gear shifting.
and let the engine idle until the warning
light turns off.
& Selection of “L” (if equipped)
S07BG03
NOTE
Please read the following points care-
fully and bear them in mind when using
the manual mode.
. If you attempt to shift down when the
engine speed is too high, i.e., when a
downshift would push the tachometer
needle beyond the red zone, beeps will
be emitted to warn you that the down-
shift is not possible.
. If you attempt to shift up when the
vehicle speed is too low, the transmis-
sion will not respond.
. You can perform a skip-shift (for
example, from 4th to 2nd) by operating
the shift paddle twice in rapid succes-
sion.
. The transmission automatically se-
lects 1st gear when the vehicle stops
moving.
. If the temperature of the transmis-
sion fluid becomes too high, the “AT
OIL TEMP” warning light on the combi-
nation meter will illuminate. Immedi-
ately stop the vehicle in a safe location
When selected, the indicator “L” will
illuminate on the combination meter.
To deselect “L”, move the select lever to
the “D” position.
“L” is for using engine braking when going
down a hill, etc. To select this mode, move
the select lever from the “D” position to the
“L” position.
& Shift lock function
S07BG04
The shift lock function helps prevent the
improper operation of the select lever.
. The select lever cannot be operated
unless the ignition switch is turned to the
“ON” position and the brake pedal is
depressed.
. The select lever cannot be moved from
the “P” position to any other position before
the brake pedal is depressed. Depress the
brake pedal first, and then operate the
select lever.
. Only the “P” position allows you to turn
