7-22
Starting and operating / Manual transmission
To change the shift lever position: 1. Depress the clutch pedal.
2. To shift into all positions other than“ R”, move the shift lever accordingly.
1) Slider
3. To shift into the“ R” position, hold up the slider, move the lever to the“ R” position, then release the slider.
4. Gradually release the clutch pedal.
If it is difficult to shift into gear, put the transmission in neutral, release the clutch pedal momentarily, and then try again.
WARNING
. Do not drive the vehicle with the clutch disengaged( i. e., when the clutch pedal is depressed) or with the shift lever in the neutral position. Engine braking has no effect in either of these conditions and the risk of an accident is consequently increased.
. Do not engage the clutch( i. e., release the clutch pedal) suddenly when starting the vehicle. By doing so the vehicle might unexpectedly accelerate or the transmission could malfunction.
CAUTION
Shift into reverse ONLY when the vehicle has completely stopped. It may cause damage to the transmission to try shifting into reverse when the vehicle is moving.
& Shifting speeds
S07AF01
! Recommended shifting speeds
S07AF0101
The best compromise between fuel economy and vehicle performance during normal driving is ensured by shifting up at the speeds listed in the following table.
Shift up |
mph( km / h) |
1st to 2nd |
15( 24) |
2nd to 3rd |
25( 40) |
3rd to 4th |
40( 64) |
4th to 5th |
45( 72) |
5th to 6th |
50( 81) |
! Maximum allowable speeds
S07AF0102
The following table shows the maximum speeds that are possible with each different gear. The tachometer’ s needle will enter the red area if these speeds are exceeded.
With the exception of cases where sudden acceleration is required, the vehicle should not be driven with the tachometer’ s needle inside the red area. Failure to observe this precaution can lead to excessive engine wear and poor fuel economy.
