Instruments and controls/Multi-function display (color LCD)
remain displayed on the screen.
! Fuel consumption screen
3-53
! Clock/date screen
S03BP101908 S03BP101909
Driving range on remaining fuel
Average fuel consumption corresponding
to the driving distance of each trip meter
Current fuel consumption The time and date are displayed.
You can adjust the time and date. For
details, refer to “Clock” F3-60.
! Audio screen
S03BP101907
The screen of the currently selected audio
source is displayed.
For details about how to use the audio set,
refer to the separate navigation/audio
Owner’s Manual.
1)
2)
3)
The fuel consumption information is dis-
played on the screen.
NOTE
The driving range on remaining fuel is
only a guide. The indicated value may
differ from the actual driving range on
remaining fuel, so you must immedi-
ately fill the tank when the low fuel
warning light illuminates.
– CONTINUED –
