3-48
Instruments and controls/Multi-function display (color LCD)
! Climate control screen
S03BP1017
The climate control status is displayed on
the multi-function display (color LCD).
Climate control screen
1) Set temperature indicator (left-hand side)
2) FULL AUTO indicator
3) AUTO indicator
4) Airflow mode indicator
5) Set temperature indicator (right-hand
side)* 1
6) Air inlet selection indicator
7) SYNC indicator* 1
8) Fan speed indicator
9) Air conditioner ON indicator
*1: Models with the SYNC function only
When operating the climate control sys-
tem, the basic screen switches to the
climate control screen. For details about
climate control operation, refer to “Climate
control panel” F4-2.
! Clock
S03BP1018
The clock can be displayed in either 12-
hour display or 24-hour display. For details
about the setting, refer to“Clock” F3-60.
