3-38
Instruments and controls/Combination meter display (color LCD)
Menu screen entering screen:
& Menu screens
S03BN07
Pull and hold the “ /SET” switch to enter
the menu screens when all of the following
conditions are satisfied.
. The menu screen entering screen is
selected.
. The “ ” information reminder is off.
NOTE
While this screen is selected, pull and hold
the “ /SET” switch to enter the menu
screen.
. While driving, the setting items
available on the combination meter
display (color LCD) are limited.
. For function settings and adjust-
ments on the combination meter dis-
play, refer to “Function settings and
adjustments on the combination meter
display (color LCD)” F25.
By operating the “ ” or “ ” switch on the
steering wheel, you can select the menu.
Pull the “ /SET” switch to enter the
selected menu.
NOTE
If you enter the “Go Back” menu, the
system will return to the previous
screen.
! Screen Settings
S03BN0701
After entering the “Screen Settings” menu,
select one of the following menus.
! Welcome Screen
S03BN070101
The welcome screen can be activated or
deactivated.
! Good-bye Screen
S03BN070106
The good-bye screen can be activated or
deactivated.
! Gauge Initial Movement
S03BN070102
The movement of the meter needles and
gauge needles that occurs when the
ignition switch is turned to the “ON”
position can be activated or deactivated.
! Units
S03BN070108
Changes the units displayed in the combi-
nation meter display (color LCD), the type
A multi-function display (black and white)
and the type B multi-function display (color
LCD).
! Tire Pressure Units (if equipped)
S03BN070109
Changes the units displayed in the Tire
Pressure Monitoring system.
! Languages
S03BN070103
Changes the language displayed in the
combination meter display (color LCD)
and the multi-function display (color LCD).
! Warning Volume (if equipped)
S03BN0713
Sets the EyeSight warning volume, the
BSD/RCTA warning volume and the RAB
