Instruments and controls / Meters and gauges 3-11
If the ECO gauge moves towards the + side, this indicates better fuel efficiency.
NOTE
. The ECO gauge shows only an approximate indication of fuel efficiency.. After resetting the trip meter, the average rate of fuel consumption is not shown until you have driven for 1 mile( or 1 km). Before that time, the ECO gauge does not operate.
& Combination meter settings
S03AD16
Meter and vehicle settings can be set on the combination meter.
! Type A combination meter
S03AD1601
Various adjustments can be made, such as switching units shown on the combination meter and adjusting the warning tone volume.
While the ignition switch is in the“ OFF” position, each press of TRIP RESET switch results in items shown in the table below being switched.
Item
Combination meter display
Possible settings
A trip—
B trip— Gauge needle sweep function
Changing the unit *
Warning volume *
On / Off
mile / km
Lv. 1 / Lv. 2 / Lv. 3
*: if available
NOTE
. If you switch the units on the combination meter, the units on the multifunction display( black and white) also switches accordingly.. If either of the following conditions is met, the combination meter setting mode will be canceled. – The driver’ s door is opened. – The TRIP RESET switch is not operated for approximately 10 seconds or more.
! Switching method
S03AD160101
1. Push the ignition switch in the“ OFF” position.
1) TRIP RESET switch
2. Press the TRIP RESET switch repeatedly until the item you want to change is displayed.
3. Press and hold the TRIP RESET switch while the item to be changed is displayed, the setting of the item will be switched.
! Type B combination meter
S03AD1602
Meter and vehicle settings can be set on the combination meter display( color LCD). Refer to“ Menu screens” ☞3-38.
