Instruments and controls/Meters and gauges
& Odometer
3-9
closed.
S03AD04
& Double trip meter
S03AD05
To set the trip meter to zero, select the A
trip or B trip meter by pressing the TRIP
RESET switch and keep the knob pressed
for more than 2 seconds.
CAUTION
1)
2)
3)
TRIP RESET switch
Type A combination meter
Type B combination meter
This meter displays the odometer when
the ignition switch is in the “ON” position.
The odometer shows the total distance
that the vehicle has been driven.
NOTE
If you press the TRIP RESET switch
when the ignition switch is in the
“LOCK”/“OFF” or “ACC” position, the
odometer/trip meter will light up.
The indicators will turn off when:
. The TRIP RESET switch is not oper-
ated for approximately 10 seconds.
. The driver’s door is opened and then
To ensure safety, do not attempt to
change the function of the indicator
during driving, as an accident could
result.
1)
2)
3)
TRIP RESET switch
Type A combination meter
Type B combination meter
This meter displays the two trip meters
when the ignition switch is in the “ON”
position.
The trip meter shows the distance that the
vehicle has been driven since you last set
it to zero.
The display can be switched as shown in
the following sequence by pressing the
TRIP RESET switch.
– CONTINUED –
