Keys and doors/Windows
! Operating the window
S02AH0702
. With one-touch auto up and down
feature:
each switch is continuously operated
in the same direction simultaneously
for a few seconds.
Either of the operations described
above may cause the power window
breaker to operate making it impossible
to open or close the window. Be sure to
initialize the power windows. If they are
not initialized, the one-touch auto up/
down function will not operate. Refer to
“Initialization of power window with
one-touch auto up/down function”
F2-30.
. Without one-touch auto up and down
feature:
! Anti-entrapment function (windows
with one-touch auto up/down func-
tion)
S02AH0703
While closing the driver’s and front pas-
senger’s windows automatically, if the
window senses a substantial enough
object trapped between the window and
the window frame, it automatically moves
down slightly and stops.
If a foreign object is caught while the
driver’s window or passenger’s window is
opening automatically, the window will
stop.
CAUTION
. Never attempt to test this func-
tion using fingers, hands or other
parts of your body.
. The anti-entrapment function
may not operate properly if some
object gets trapped just before
the window fully closes.
1) Automatically close*
2) Close
3) Open
4) Automatically open*
*: To stop the window halfway, operate the
switch to opposite side.
NOTE
Avoid the following.
. After the driver’s window is fully
closed or fully opened, the switch is
continuously operated in the same
direction for a few seconds.
. After the windows for three or more
seats are fully closed or fully opened,
2-29
NOTE
1)
2)
Close
Open
. If a window detects an impact similar
to that caused by trapping an object (for
example, when the vehicle encounters
a deep pothole), the anti-entrapment
function may operate.
. The window cannot be operated for a
– CONTINUED –
