7-62
Starting and operating/Reverse Automatic Braking System
party except under the following con-
ditions.
. The vehicle owner has given his/her
consent.
. The disclosure/provision is based
on a court order or other legally en-
forceable request.
. Data that has been modified so that
the user and vehicle cannot be identi-
fied is provided to a research institution
for statistical processing or similar
purposes.
& Reverse Automatic Braking
System overview
The system detects objects using sonar
sensors installed in the rear bumper.
. If the system determines a possible
collision with an object in the reversing
direction, automatic deceleration will be
activated. Also, beeping sounds will acti-
vate.
. If the vehicle is further reversed, auto-
matic hard braking will be applied and a
continuous beeping sound will activate.
! Detecting range
cancel the system, refer to “Cancel-
ing the Reverse Automatic Braking
system operation” F7-67.
& Operating conditions
The Reverse Automatic Braking system
will operate when all of the following
conditions are met.
1)
2)
3)
Detecting range (width): Approximately 6
in (15 cm) outside of the vehicle width
Range that the system cannot detect:
Approximately 20 in (50 cm) behind the
rear of the vehicle
Detecting range (length): Approximately
5 ft (1.5 m) from the rear of the vehicle
WARNING
If your vehicle is trapped on a rail-
road crossing and you are trying to
escape by reversing through the
crossing gate, the system may re-
cognize the crossing gate as an
obstacle and the brake may activate.
In this case, remain calm and either
continue to depress the accelerator
pedal or cancel the system. To
1)
2)
3)
EyeSight warning indicator
RAB warning indicator
RAB OFF indicator
. The ignition switch is in the “ON”
position
. The EyeSight warning indicator is off
. The RAB warning indicator is off
. HALT (RAB OFF) indicator is off
. The Reverse Automatic Braking sys-
