Audio/Audio set
NOTE
. If the audio control screen appears,
select the “Source” key on the audio
screen or press the AUDIO/TUNE knob
again.
. When you push the AUDIO/TUNE
knob while any screen other than the
audio control screen is displayed, the
display will return to the audio control
screen.
. When the AUDIO/TUNE knob is
pushed and held, the graphic equalizer
screen will be displayed. Refer to
““Graphic Equalizer”” F5-23.
! Selecting a function menu
Press the HOME button to display home
screen.
Item
Function
AUDIO
Select to display the main
screen of the audio source that
was selected previously.
PHONE
Select to display the hands-free
function using your cell phone.
Refer to “Hands-free phone
system” F5-70.
APPS
Select to display the functions
linked with a smartphone. Refer
to “SUBARU STARLINK” F526.
5-19
tab to set
. Sound settings: Select the
the sound quality settings. Refer to
“Sound settings” F5-20.
tab to
. Display settings: Select the
set the screen settings. Refer to “Display
settings” F5-25.
. SUBARU STARLINK settings (if
tab set the
equipped): Select to the
SUBARU STARLINK settings. Refer to
“SUBARU STARLINK settings” F5-26.
Select to display the functions
SETTINGS for performing various settings.
Refer to “Unit settings” F5-19.
& Unit settings
Sound quality adjustment, screen adjustment, and information of the audio unit are
displayed.
1. Press the HOME button on the audio
panel.
2. Touch the “SETTINGS” key.
3. Select the items to be set.
Available setting:
tab to
. General settings: Select the
check the system software update information. Refer to “General settings” F5-20.
. Bluetooth settings: Select the
tab to
set the Bluetooth settings. Refer to “Bluetooth settings” F5-20.
– CONTINUED –
