3-100
Instruments and controls/Defogger and deicer
! Remote control mirror switch
: Select side to adjust
: Direction control
The remote control mirrors operate only
when the ignition switch is in the “ON” or
“ACC” position.
1. Turn the control switch to the side that
you want to adjust. “L” is for the left mirror,
“R” is for the right mirror.
2. Move the control switch in the direction
you want to move the mirror.
3. Return the control switch to the neutral
position to prevent unintentional operation.
The mirrors can also be adjusted manually.
Defogger and deicer
window defogger. Some models are also
equipped with an outside mirror defogger
and/or windshield wiper deicer. The defogger and deicer system is activated only
when the ignition switch is in the “ON”
position.
Climate control system type A and type B
1)
2)
3)
Rear window defogger
Outside mirror defogger (if equipped)
Windshield wiper deicer (if equipped)
The vehicle is equipped with a rear
