3-98
Instruments and controls/Wiper and washer
& Rear window wiper and
washer switch
Windshield washer fluid warning light
(type B)
The windshield washer fluid warning
light illuminates when the washer fluid
level in the tank has dropped to the
lower limit. If the warning light illuminates, refill the tank with fluid. For the
refilling procedure, refer to “Windshield washer fluid” F11-28.
(accompanied by wiper op: Washer
eration)
: Continuous
: Intermittent
: Off
Washer (accompanied by wiper op: eration)
! Rear wiper
To turn the rear wiper on, turn the knob
switch upward.
To turn the wiper off, return the knob
switch to the “ ” position.
” posiWith the switch turned to the “
tion, the rear wiper will operate intermittently at intervals corresponding to the
vehicle speed. In this position, when you
move the select lever to the “R” position
(CVT models) or the shift lever to the
reverse position (MT models), the rear
wiper will switch to continuous operation.
When you move the select lever/shift lever
from the “R” (reverse) position to another
position, the rear wiper will return to
intermittent operation.
Reverse gear interlocked rear wiper:
Even if the rear wiper switch is in the off
“ ” position, if the front windshield wiper is
operating continuously, the rear wiper will
operate intermittently when you move the
select lever/shift lever to the “R” (reverse)
position.
The factory setting (default setting) of the
reverse gear interlocked rear wiper is as
follows.
. U.S.-spec. models: Non-operational
. Other models: Operational
