3-48
Instruments and controls/Multi function display
! Clock
The clock can be displayed in either 12hour display or 24-hour display. For details
about the setting, refer to “Current date
and time setting” F3-56.
! Fuel consumption screen
! ECO gauge screen (if equipped)
NOTE
If the vehicle battery is disconnected,
the clock shown in the information bar
will be reset. Set the time again after
the vehicle battery is connected. For
details about the setting, refer to “Top
display setting” F3-65.
1)
2)
3)
Average fuel consumption corresponding
to the driving distance of each trip meter
Current fuel consumption
Driving range on remaining fuel
The displayed location can be customized. For details, refer to “Fuel consumption screen setting” F3-66.
1)
2)
Average fuel consumption corresponding
to the driving distance of each trip meter
ECO gauge
The gauge pointer shows the difference
between the current fuel consumption and
the average fuel consumption that is
displayed on the center part of the screen.
If the gauge pointer moves toward the
green side, this indicates better fuel
efficiency.
