Instruments and controls/Multi function display
Fuel consumption results screen
1) The average fuel consumption for the
entire driving distance, from when the
ignition switch was turned to the “ON”
position to when it was turned to the
“LOCK”/“OFF” position.
2) This display shows the average rate of
fuel consumption since the trip meter
was last reset. It displays the average
fuel consumption corresponding to the A
trip meter mileage or the one corresponding to the B trip meter mileage.
& Self-check screen
When the ignition switch is turned to the
“ON” position, the vehicle self-check will
be performed. The screens corresponding
to the following items will appear one after
another for several seconds each.
1)
2)
3)
4)
Engine oil: Checks the interval of engine
oil replacement.
Oil filter: Checks the interval of oil filter
replacement.
Tires: Checks the interval of tire rotation.
Inspection and maintenance: Checks the
interval of inspection and maintenance.
When the checks are performed, the color
of the icon corresponding to the checked
item will turn green.
If there is no warning message, the selfcheck will be complete without notification.
3-45
Example of notification
If there is a warning message or a
maintenance notification, the color of the
icon corresponding to the item will turn
yellow and the warning message or the
maintenance notification will be displayed.
Take the appropriate actions based on the
messages indicated.
NOTE
. The self-check screen can be set to
on or off. For details, refer to “On/Off
setting” F3-74.
. After performing the maintenance,
change the setting of the corresponding maintenance item. For details, refer
to “Maintenance settings” F3-73.
. The maintenance notification screen
will be displayed under either of the
– CONTINUED –
