2-32
Keys and doors/Alarm system
& Tripped sensor identification
The security indicator light flashes when
the alarm system has been triggered.
Also, the number of flashes indicates the
location of unauthorized intrusion or the
severity of impact on the vehicle.
1)
2)
ON
LOCK
2. Turn the ignition switch from “ON” to
“LOCK” position and remove the key from
the ignition switch.
3. Open the doors and get out of the
vehicle.
4. Before closing the doors, lock all doors
with the inside door lock levers.
5. Close the doors. The system will
automatically arm after 1 minute.
In the passive mode, the system can also
be armed with the remote transmitter or
with the power door locking switches. If
the remote transmitter or power door
locking switch is used to lock the vehicle,
arming will take place immediately regardless of whether or not the passive mode
has been selected.
! Disarming the system
To disarm the system, briefly press the
“ ” button on the transmitter.
When the ignition switch is turned to the
“ON” position, the indicator light will light
for 1 second and then flash as follows.
. When a door or the rear gate was
opened: 5 times
. When the ignition switch was turned to
the “ON” position: 3 times
. When a strong impact or multiple
impacts were sensed: twice (only models
with shock sensors (dealer option))
. When a light impact was sensed: once
(only models with shock sensors (dealer
option))
NOTE
Any of the above indicator light flashings will recur each time the ignition
switch is turned to the “ON” position.
Rearming the alarm system cancels the
flashing.
