1-38
Seat, seatbelt and SRS airbags/Child restraint systems
For the center seating position on 5-
door models, route the top tether under
the head restraint as illustrated below.
Three upper anchorages are installed on
the back side of the rear seatback.
! To hook the top tether
CAUTION
. Except for the center seating
position on 5-door models, re-
move the head restraint when
mounting a child restraint sys-
tem. Otherwise, it might be pos-
sible that the top tether cannot be
fastened tightly.
. For the center seating position on
5-door models, raise the center
head restraint to the extended
position when mounting a child
restraint system. Otherwise, it
will be impossible to use the
seatbelt guide that is attached
to the head restraint correctly.
The seatbelt guide is essential
for routing the belt webbing at
the center seating position. For
information about using the seat-
belt guide, refer to “Rear center
seatbelt on 5-door models” F1-
16.
4-door models
1)
2)
3)
Seatbelt guide
Seatbelt of the center seating position
Top tether
2. Tighten the top tether securely.
Please contact your SUBARU dealer if
you have any question regarding the
installation of a child restraint system.
5-door models
1. Open the cover (4-door models) and
attach the top tether hook to the appro-
priate upper anchorage.
