1-38
Seat, seatbelt and SRS airbags/*SRS airbag (Supplemental Restraint System airbag)
*SRS airbag (Supplemental
Restraint System airbag)
*SRS: This stands for supplemental restraint system. This name is used because the airbag system supplements the
vehicle’s seatbelts.
1. Attach the top tether hook to the
appropriate upper anchorage.
For the center seating position, route
the top tether under the head restraint as
illustrated below.
1)
2)
3)
Seatbelt guide
Seatbelt of the center seating position
Top tether
2. Tighten the top tether securely.
Please contact your SUBARU dealer if
you have any question regarding the
installation of a child restraint system.
Your vehicle is equipped with a supplemental restraint system in addition to a
lap/shoulder belt at each front seating
position and each rear window-side seating positions. The supplemental restraint
system (SRS) consists of seven airbags.
The configurations are as follows.
. Driver’s and front passenger’s frontal
airbags
. Driver’s and front passenger’s side
airbags
. Curtain airbags (for driver, front passenger, and window-side rear passengers)
. Knee airbag for driver
These SRS airbags are designed only
as a supplement to the primary protection provided by the seatbelt.
The system also controls front seatbelt
pretensioners. For operation instructions
and precautions concerning the seatbelt
pretensioner, refer to “Front seatbelt pretensioners” F1-20.
