17
Display
Status
Display
Operating/stopping of the electric
motor
(1) While stopped
(illuminated in
gray)
(2) While operating (illuminated in green
or aqua blue)
When charging the
high voltage battery by using the
engine power
while the vehicle is
stopped
When there is no
energy current
Remaining high
voltage battery
power is
(1) low
(2) high
Operating/stopping of the engine
(1) While stopped
(illuminated in
gray)
(2) While operating (illuminated in orange)
Status
In addition, if a warning or malfunction is
detected in the hybrid system, an interruption screen will be displayed on the
multi function display. For details, refer to
“Interruption screen” F3-34.
NOTE
. High voltage battery power is consumed more than usual when driving
only using the electric motor power for
a long time.
. High voltage battery power is consumed more than usual when the
vehicle is continuously or repeatedly
driven only using the electric motor
power. Although this is not a problem,
avoid stop-and-go driving as much as
possible by methods such as checking
traffic reports before you start driving.
. The indicator of the remaining high
voltage battery power may show empty
when the remaining power is extremely
low. However, this does not indicate a
malfunction.
