About EyeSight

Set vehicle speed display
Displays the set vehicle speed.
Refer to pages 38 and 67.

Selector indicator/shift position indicator
This indicator illuminates and shows which position the selector lever or the gear is in.

EyeSight warning indicator (yellow)
This indicator illuminates or flashes when a malfunction occurs in the EyeSight system.
When it is illuminated or flashing, none of the EyeSight functions can be used (including
Adaptive Cruise Control and the Pre-Collision Braking System, etc.).
Refer to page 77.

EyeSight temporary stop indicator (white)
This indicator illuminates when the EyeSight system is temporarily stopped.
When the ignition switch is placed in the ON position, it will illuminate if the
(CRUISE) switch is set to ON within approximately 7 seconds of the engine starting. It
turns off when approximately 7 seconds have elapsed since the engine started.
When it is illuminated, none of the EyeSight functions can be used except for Conventional Cruise Control.
Refer to page 78.

Lane Departure Warning OFF indicator light
This indicator illuminates when the Lane Departure Warning and Lane Sway Warning are
off.
It also illuminates when the ignition switch is turned to the ON position, and then approximately 7 seconds after the engine starts, the Lane Departure Warning will be turned on.
The default setting for the Lane Departure Warning when the vehicle is restarted is “ON”.
Refer to page 60.

Pre-Collision Braking System OFF indicator light
Illuminates when the Pre-Collision Braking System and Pre-Collision Throttle
Management are off.
It also illuminates when the ignition switch is turned to the ON position, and then turns off
approximately 7 seconds after the engine starts.
Refer to page 31.

15
