7-28
Starting and operating/Continuously variable transmission
& Selection of “L” (if equipped)
illuminate on the combination meter.
To deselect “L”, move the selector lever to
the “D” position.
& Shift lock function
“L” is for using engine braking when going
down a hill, etc. To select this mode, move
the selector lever from the “D” position to
the “L” position.
When selected, the indicator “L” will
The shift lock function helps prevent the
improper operation of the select lever.
. The select lever cannot be operated
unless the ignition switch is turned to the
“ON” position and the brake pedal is
depressed.
. The select lever cannot be moved from
the “P” position to any other position
before the brake pedal is depressed.
Depress the brake pedal first, and then
operate the select lever.
. Only the “P” position allows you to turn
the ignition switch from the “ACC” position
to the “LOCK” (off) position and remove
the key from the ignition switch.
. If the ignition switch is turned to the
“LOCK” (off) position while the select lever
is in the “N” position, the select lever may
not be moved to the “P” position after a
period of time. Therefore, move the select
lever to the “P” position with the brake
pedal depressed soon after the ignition
switch is turned to the “LOCK” (off)
position.
! Shift lock release
If the select lever cannot be operated, turn
the ignition switch back to the “ON”
position then move the select lever to the
“P” position with the select lever button
pressed and brake pedal depressed.
If the select lever does not move after
performing the above procedure, perform
the following steps.
. When the select lever cannot be
shifted from “P” to “N”:
Refer to “Shift lock release using the shift
lock release button” F7-29.
. When the select lever cannot be
shifted from “N” to “R”, “P”:
Within 60 seconds after placing the ignition switch in the “ACC” position, move the
select lever to the “P” position with the
select lever button pressed and brake
pedal depressed.
If you must perform the above procedure,
the shift lock system (or the vehicle control
system) may be malfunctioning. Contact a
SUBARU dealer for an inspection as soon
as possible.
If the select lever does not move after
performing the above procedure, refer to
“Shift lock release using the shift lock
release button” F7-29.
