Instruments and controls/Meters and gauges
your vehicle under emergency conditions.
The hazard warning flasher works regardless of the position of the ignition switch.
Meters and gauges
To turn on the hazard warning flasher,
push the hazard warning button on the
instrument panel. To turn off the flasher,
push the button again.
Liquid-crystal displays are used in
some of the meters and gauges on
the combination meter. You will find
their indications hard to see if you wear
polarized glasses.
NOTE
When the hazard warning flasher is on,
the turn signals do not work.
NOTE
& Combination meter illumination
When the ignition switch is turned to the
“ON” position, the various parts of the
combination meter are illuminated in the
following sequence.
3-9
& Canceling the function for
meter/gauge needle movement upon turning on the
ignition switch
It is possible to activate or deactivate the
movement of the meter needles and
gauge needles that takes place when the
ignition switch is turned to the “ON”
position.
! Type A combination meter
To change the setting, perform the following procedure.
1. Turn the ignition switch to the “LOCK”
(off) or “ACC” position.
1. Warning lights, indicator lights, meter
needles, gauge needles and liquid crystal
display illuminate.
2. Meter and gauge indications each
show MAX position.
3. Meter and gauge indications each
show MIN position.
4. Regular illumination (for driving) begins.
1)
Trip knob
2. Press the trip knob to show “
“ ” on the trip meter display.
” or
– CONTINUED –
