BASIC OPERATION

North-up screen

: 2D heading-up and 3D symbol
The direction of vehicle travel is always up.
The letter(s) indicate the vehicle’s heading direction
(e.g. N for north).

POSITION MARKER
SELECTED MAP LOCATION (CURSOR)
Heading-up screen
Use one of the following methods to mark a map location.
Select the map during navigation.

Select the map in “Find on Map (Find on Map)”.

3D screen

You can use the cursor’s position as the route’s destination,
search for locations around the cursor, and save the position
in the destination list.
After selecting a map location, a cursor is displayed
at the point selected on the map. The cursor is
) and can be checked at
displayed as a red point (
all zoom levels.

: 2D north-up symbol
Regardless of the direction of vehicle travel, north is
always up.
191

NAVIGATION SYSTEM

Select the map when the destination you want is
displayed in the search results.

8
