Maintenance and service/Replacing bulbs
11-43
pins and a catch with the guide holes and
a clip on the vehicle.
1)
2)
3)
4)
Rear side marker light
Tail light
Backup light
Rear turn signal light
7. Reconnect the electrical connector.
9. Tighten the upper and lower screws.
4. Remove the bulb socket from the rear
combination light assembly by turning it
counterclockwise.
5. Pull the bulb out of the bulb socket and
replace it with a new one.
6. Set the bulb socket into the re
